LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
Parts List (continued)
Parts A05–W15 Parts W17–47 Front Case View Rear View Main Assemblies
Item Quantity MIN CAT. Part Description Note
37 1 3200637-001 21300-004836 Door hinge plate Part of kit MIN 3202718-001
41 1 3201610-000 21300-004649 Bracket, speaker mounting
43 1 3200913-003 21300-004233 Display lens Part of various kits
47 1 3200640-015 21300-004838 Active display bracket Part of various kits
161 3 200805-000 21300-000584 Locking hex nut, 4-40
173 10 202253-761 21300-001038 Machine screw, 4-40  0.312L
199 1 3202056-XXX see note AED door assembly Part of kit MIN 3202360
201 1 3201111-003 21300-004241 Thermally conductive backlight
inverter pad
219 3 3202246-003 21300-004254 Grounding strap harness Active Display
221 2 3202246-004 21300-004255 Grounding strap harness User Interface PCB
9-29
