LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
A03 Power Module
Installation
To install the power module assembly:
1. Ensure that the right rear corner 4-400.312 screw (173) is loosely installed
(back off 3 to 5 turns) in the bottom case.
2. Position the power module in the bottom case ensuring that the notch in the
rear right lip slips into place under the loosened screw.
3. Install a new 4-400.312 screw (173) in the power bracket’s left forward
corner; torque to 6.8 in-lb.
4. Insert a 4-400.312 screw (173) through the grounding strap (221) ring, and
install the screw in the power bracket’s right forward corner; torque to 6.8 in-
lb.
Note: If broken or frayed, replace the grounding strap.
5. Tighten the 4-400.312 screw (173) in the rear right corner; torque to 6.8 in-
lb.
6. Install the A13 Energy Capacitor, if it was removed.
7. Install the boardstack, if it was removed.
8. Connect the W09 26-Pin Cable between the A03 Power Module at J41 and
the A04 Therapy PCB at J16.
Parts List Interconnect Diagram Module View Connectors View Main Assemblies
