LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
A03 Power Module
Installation (continued)
9. Connect the 4-pin W10 Power/Therapy Cable connector to the A04 Therapy
PCB at J17.
10. Install the A12 Printer Module.
11. Install the front case.
12. Install the top case.
13. Install the A07 Battery.
14. Complete the LIFEPAK 20 Device PIP.
Parts List Interconnect Diagram Module View Connectors View Main Assemblies
9-129
