LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
A03 Power Module
Removal
Note: Remove the following assemblies before beginning this disassembly:
– A07 Battery
– Top case
– Printer module
– Capacitor (optional removal)
– Boardstack (optional removal)
To remove the power module assembly:
1. If the boardstack assembly is installed in the bottom case, continue with
step 2. If the boardstack assembly has been removed, proceed to step 5.
2. Disconnect the W10 Power/Therapy Cable from the A04 Therapy PCB at
J17.
3. Disconnect the W09 26-Pin Cable from the A04 Therapy PCB at J16.
WARNING
SHOCK HAZARD. Carefully follow disassembly instructions to avoid a shock or
causing damage to wires during disassembly.
Parts List Interconnect Diagram Module View Connectors View Main Assemblies
9-126
