LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
Grounding Harness
Orientation
To ensure that the top case, front case, and bottom case join correctly, align the
grounding harnesses as shown below and on the next page.
(Continued on next page)
