LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
W05 SpO2 Connector
Installation
To install the W05 SpO2 Connector Assembly:
1. Place the W05 SpO2 input connector into the locating detail in the bottom
case.
2. Position the SpO2 connector mounting clip (113) in front of the mounting
block detail on the bottom case.
3. Press the SpO2 connector mounting clip in and down onto the bottom case
mounting block detail until the snap arms click into position.
4. Install a cable tie retainer (229) to secure the ferrite bead to the bottom case.
5. Install the W03 IrDA Assembly.
6. Install the boardstack.
7. Install the front case.
8. Install the top case.
9. Install the A07 Battery.
10. Complete the LIFEPAK 20 Device PIP.
