LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
W02 Speaker Assembly
and W25 Speaker
Harness Extension
Cable Diagrams
W02 Speaker Assembly (front case)
MIN 3319086-001 (RoHS) or
3201593-004 (non-RoHS)
W25 Speaker Harness Extension Cable (bottom case)
MIN 3319086-000 (RoHS) or 3201593-003 (non-RoHS)
1
6
P05
J05
Interconnect
9-62
