LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
Parts List
(Continued on next page)
Parts W17–47 Parts 161–284 Front Case View Rear View Main Assemblies
Item Quantity MIN CAT. Part Description Note
A05 1 3317230-002 see note User Interface PCB Part of kit MIN 3202718-044,
3202718-045, 3202718-046
A08 1 3202033 see note Backlight Inverter, CCFT,
LCD, 1.5KV Out, 8to20V in
Part used with A11 - 3205278
Part of kit MIN 3202718-009
A08 1 3308907 see note Module-OEM, LED Driver
(Backlight Inverter)
Part used with A11 - 3309555
Part of kit MIN 3202718-032
A11 1 3205278 see note Active Display, Color LCD Part of kit MIN 3202718-008
A11 1 3309555 see note Active Display, Color LED Requires A05 - 3317230-002 or
greater and Redux Device S/W
Part of kit MIN 3202718-032
A15 1 3200642-XXX see note Elastomer Keypad Select other language
9-27
