LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Service Replacement Kits (continued)
KIT-REPAIR, DISPLAY FOR
UI 3201966-005 AND -006
(Pre-Redux)
MIN 3202718-008
KIT-REPAIR, BACKLIGHT
INVERTER FOR UI 3201966-
005 AND -006 (Pre-Redux)
MIN 3202718-009
Item Quantity MIN CAT. Part Description
A11 1 3205278-001 Active Color LCD Display
W15 1 3300152-000 21300-007774 Active Display Cable
43 1 3200913-003 21300-004233 Display lens
173 4 202253-761 21300-001038 Screws 4-40 x 0.312
266 1 3205497-308 21300-006141 Nylon snap rivet
Item Quantity MIN CAT. Part Description
A08 1 3202033-500 Backlight Inverter
W17 1 3200996-002 21300-004237 Active Backlight Inverter
Cable
47 1 3200640-015 21300-004838 Active Display Bracket
203 1 3202018-000 21300-004250 Extender cable (for Sanyo
display devices)
9-185
