LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Boardstack (continued)
Boardstack Removal .
Note: Remove the following assemblies before beginning this disassembly:
– Top case
– Front case
To remove the boardstack assembly:
1. Turn the device so the ECG and therapy connectors are in view, and then set
the device on its left side.
2. Disconnect the grounding harness (219) that connects the power module to
the PCB support bracket (139) by removing the screw.
Note: Replace the grounding harness if broken or frayed.
3. Turn the device so the ac power connector is in view.
4. Disconnect the 4-pin W10 Power/Therapy Cable connector from the A04
Therapy PCB at J17.
WARNING
SHOCK HAZARD. Carefully follow disassembly instructions to avoid a shock or
damage to wires during disassembly.
Parts Lists Interconnect System View Therapy View Main Assemblies
9-72
