LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Boardstack (continued)
A04 Therapy PCB
Assembly Diagram
With Pacing:
MIN 3317228-000 (RoHS) or
3202259-010 (non-RoHS)
Without Pacing:
MIN 3317228-001 (RoHS) or
3202259-011 (non-RoHS)
A04 Therapy PCB Removal
■ Inductive Resistor
A04 Therapy PCB
Installation
139
A04
147- No longer
185 (x5)
161 (x3)
135 Ref
123 (x5)
W07
229
145 (x3)
A14
173
used in assembly
Interconnect
9-64
