LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
Bottom Case
Reassembly
To reassemble the bottom case:
1. Obtain a new bottom case (if replacing case).
2. Inspect and install the bottom case friction foot pads (105), as needed.
3. Inspect and install the mounting foot (227) to the battery door (103), as
needed.
4. Install the W25 Speaker Harness Extension Cable.
5. Install the W03 IrDA Connector.
6. Install the W05 SpO2 Connector.
7. Install the W06 ECG Connector.
8. Install the W01 Therapy Connector.
9. Install the A03 Power Module.
10. Install the A13 Energy Capacitor.
11. Install the A12 Printer Module.
12. Install the boardstack assembly.
(Continued on next page)
