LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table
Code Service Code Description Corrective Action
0002 System Flash memory voltage error Replace the A01 System PCB
0003 Cannot erase system Flash memory Replace the A01 System PCB
0004 Cannot write to system Flash memory Replace the A01 System PCB
0006 System ADC read error Replace the A01 System PCB
0007 System DAC not responding Replace the A01 System PCB
0008 ECG OUT DAC self-test failed Replace the A01 System PCB
000a System ADC background test failed Replace the A01 System PCB
000b System ADC failed self-calibration Replace the A01 System PCB
000c System Flash memory ID unknown Replace the A01 System PCB
000d System hardware/software configuration lost Replace the A01 System PCB
100e UI – system communication lost 1. Replace the W18 UI Flex Cable
2. Replace the A05 UI PCB
3. Replace the A01 System PCB
100f Display update timer error 1. Reload the device software*
2. Replace the A01 System PCB
* Use software loader tool in forced update mode (Continued on next page)
A01 System PCB A05 UI PCB W18 UI Flex Cable
6-13
