LIFEPAK 20/20e Defibrillator/Monitor Device Description
Physical Description and Features (continued)
LIFEPAK 20/20e
Front Panel
(continued)
Number Description
7 Service indicator LED — Illuminates when the device enters
service error codes into the Service Log (accessed through the
SERVICE menu). Refer to Troubleshooting for information about
the error codes.
8 ECG cable connector — Connection port for the electrically
isolated ECG patient cable.
9 SpO2 cable connector — Connection port for the pulse oximeter.
10 IrDA port connector — Infrared connection port provides wireless
communications to data management devices (this feature is not
available with this release).
11
SPEED DIAL selector — When active (SPEED DIAL LED is on), turn
(either direction) to make a selection from the menu or overlay
shown on the screen; press to confirm your selection.
12
SPEED DIAL LED — Illuminates when the SPEED DIAL is active.
13
ALARMS control — Press to activate and silence alarms.
3-9
