LIFEPAK 20/20e Defibrillator/Monitor Device Description

Physical Description and Features (continued)

LIFEPAK 20/20e

Front Panel

(continued)

(Continued on next page)

Number Description

1 Display screen — Color liquid crystal display (LCD) screen displays

operating messages, waveforms, status messages, setup menus,

and so forth.

2 EVENT control — Press to activate user-defined events.

HOME SCREEN control — Press to return to the home screen of the

particular option or feature you are configuring. Pressing this button

does not take you to a specific screen; instead, it returns to the

home screen for the mode or event you are configuring.

CODE SUMMARY control — Press to print the CODE SUMMARY

critical event record.

5 PRINT control — Press to start and stop the printer.

6 AC Mains LED - When the ac power (line power) is connected, the

AC mains light is steady.

3-8
