LIFEPAK 20/20e Defibrillator/Monitor Device Description
Physical Description and Features (continued)
LIFEPAK 20/20e
Front Panel
(continued)
Number Description
14
OPTIONS control — Press to access the OPTIONS menu.
15 Therapy cable connector — Connection port for the following:
– QUIK-COMBO electrodes (standard)
– FAST-PATCH electrodes (with optional cable)
– REDI-PAK electrodes (optional)
– Standard adult and pediatric paddles (optional)
– Internal paddles (optional)
– Posterior paddle (optional)
16 Speaker — Provides audio voice prompts and alert tones.
17
PAUSE control — Press to temporarily slow the pacing rate.
18
CURRENT control — Press to adjust the pacing current.
19
RATE control — Press to select a pacing rate.
(Continued on next page)
3-10
