LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
Bottom Case
Disassembly
To disassemble the bottom case:
1. Remove the A07 Battery.
2. Remove the top case.
3. Remove the front case.
4. Remove the boardstack assembly.
5. Remove the A12 Printer Module.
6. Remove the A13 Energy Capacitor.
7. Remove the A03 Power Module.
8. Remove the W01 Therapy Connector.
9. Remove the W06 ECG Connector.
10. Remove the W05 SpO2 Connector.
11. Remove the W03 IrDA Connector.
12. Remove the W25 Speaker Harness Extension Cable.
Parts List Interconnect Diagram Module View Connectors View Main Assemblies
