LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
Parts List
(continued)
Parts A03–W09 Parts W10–95 Parts 99–183 Module View Connectors View Main Assemblies
Item Quantity MIN CAT. Part Description Note
183 1 3201643-012 see note Serial number label, LIFEPAK 20 Refer to Labels Assembly
183 1 3201643-016 see note Serial number label, LIFEPAK 20e Refer to Labels Assembly
221 1 3202246-004 21300-004255 Grounding strap harness
225 1 3202377-010 21300-004400 Plastic Fastener
227 1 802885-01 21300-002138 Mounting foot Attached to battery door (103)
229 2 200536-001 21300-000499 Cable tie retainer Part of kit MIN 3202718-025
238 1 3206900-001 21300-006962 Dielectric shield Part of kit MIN 3202718-024
241 1 3300694-000 21300-007794 Poron Foam, Capacitor Part of kit MIN 3202718-025
268 1 3203445-001 21300-005784 Seal, Therapy Connector Mount Part of kit MIN 3202718-043
(RoHS)
268 1 3203445-001 21300-005784 Seal, Therapy Connector Mount Part of kit MIN 3202718-026
(non-RoHS)
270 1 3206152-000 21501-001625 Label, NIMH Battery Warning LIFEPAK 20e only
9-113
