LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
Parts List (continued)
(Continued on next page)
Parts A03–W09 Parts W10–95 Parts 221–270 Module View Connectors View Main Assemblies
Item Quantity MIN CAT. Part Description Note
W25 1 3319086-000
(RoHS)
21300-008132 Speaker Assembly Harness Ext.
W25 1 3201593-003
(non-RoHS)
21300-004246 Speaker Assembly Harness Ext.
12 sheet 3201640 see note Label Set (6 labels), LIFEPAK 20 Refer to Labels Assembly
12 sheet 3206034 see note Label Set (6 labels), LIFEPAK 20e Refer to Labels Assembly
22 2 3202228-562 21300-003883 Standoff-Hex, M/F,4-40,0.188 Part of kit MIN 3202718-024
83 1 3201408-000 21300-004621 Printer Bezel
89 1 3200626-004 21300-004306 Printer Shroud
93 2 804447-36 21300-007458 Foam Spacer (part of A13 assy)
95 2 3200922-000 21300-004619 Capacitor Support Bracket Part of kit MIN 3202718-024
9-111
