LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
Parts List (continued)
Parts A03–W09 Parts W10–95 Parts 99–183 Module View Connectors View Main Assemblies
Item Quantity MIN CAT. Part Description Note
99 1 3201597-000 21300-004653 EMI Foam Core Gasket
103 1 3200628-002 21300-004835 Battery Door, LIFEPAK 20
103 1 3200628-004 21300-006412 Battery Door, LIFEPAK 20e
105 4 802885-00 21300-002137 Mounting Foot Part of bottom case assembly
111 1 200040-001 21300-000149 Therapy Retaining Ring Part of kit MIN 3202718-043
(RoHS)
111 1 200040-001 21300-000149 Therapy Retaining Ring Part of kit MIN 3202718-026
(non-RoHS)
113 1 3200921-000 21300-004602 SpO2 Connector Mounting Clip Part of kit MIN 3202718-013
159 1 3200625-006 21300-004889 Bottom case assembly
162 1 3009787-003 21300-004110 Capacitor shield (part of A13 assembly) Part of kit MIN 3202718-025
173 12 202253-761 21300-001038 Machine screw 4-40  0.312L
9-112
(Continued on next page)
