LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Final Assembly
Device Labeling
Including Label Set (12)
3201640 - LIFEPAK 20
3206034 - LIFEPAK 20e
To apply the labels to the device:
1. Remove the old labels and clean the device with isopropyl alcohol.
2. Select the correct label set (language).
3. Apply the labels (refer to the next page for placement):
Item MIN (ref) Part Description Note
12 - Label set 3201290 Rear connector label A in Labels Assembly diagram
12 - Label set 3201274-030 Front connector label, ENG
(SpO2)
B in Labels Assembly diagram
12 - Label set 3201274-015 Front connector label, ENG
(no SpO2)
B in Labels Assembly diagram
12 - Label set 3201275 Physio-Control logo label C in Labels Assembly diagram
12 - Label set 3201273 Product ID label D in Labels Assembly diagram
12 - Label set 3009060 FDA label E in Labels Assembly diagram
12 - Label set 3202375 Masimo patent label F in Labels Assembly diagram
23 3201499 Manual latch label Select language
183 3201643 Serial number label SN label illustration
284 3206926-001 Label - Adult VF Dose, ENG Select language
9-152
