LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
W25 Speaker Harness
Extension Cable
Installation
To Install the W25 Speaker Harness Extension Cable:
1. Feed the W25 Speaker Harness Extension Cable under the W01 Therapy
Connector Assembly.
2. Insert the W25 Speaker Harness Extension Cable into the holder in the
bottom case.
3. Install the cable tie retainer (229) in the set of holes 0.5 inches to the left of
the W01 Therapy Connector Assembly, and secure the extension cable’s
ferrite ring to the bottom case.
4. Install the boardstack.
5. Install the front case.
6. Install the top case.
7. Install the A07 Battery.
8. Complete the LIFEPAK 20 Device PIP.
