LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
A13 Energy Capacitor
Installation (continued)
7. Ensuring that the capacitor brackets are centered on the poron tape connect
the capacitor cable to the A04 Therapy PCB at J2. The W07 Capacitor
Discharge Cable is attached at pin 4 of this connector.
8. Secure the W07 Capacitor Discharge Cable to the inductive resistor bracket
(141) with a cable tie retainer (229). Route the cable over the A04 Therapy
PCB using the same routing (see illustration) as the inductive resistor
cables.
9. Install the power module, if not installed.
10. Install the boardstack, if not installed.
11. Reconnect the 4-pin W10 Power/Therapy Cable connector to the A04
Therapy PCB at J17. Reseat the boardstack assembly.
12. Install a new 4-40 0.312 screw (173) and fasten the ground cable (221) to
the boardstack; torque to 6.8 in-lb.
13. Install the front case.
14. Install the top case.
15. Install the A07 Battery.
16. Complete the LIFEPAK 20 Device PIP.
