LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
(Continued on next page)
A04 Therapy PCB
Code Service Code Description Corrective Action
9c13 Therapy PCB 15 V out of range Replace the A04 Therapy PCB
9c14 Therapy PCB -15 V out of range Replace the A04 Therapy PCB
9c15 Therapy ADC time out error Replace the A04 Therapy PCB
9c18 3:00 AM H bridge test: NE leg shorted Replace the A04 Therapy PCB
9c19 3:00 AM H bridge test: SE leg shorted Replace the A04 Therapy PCB
9c1a 3:00 AM H bridge test: NW leg shorted Replace the A04 Therapy PCB
9c1b 3:00 AM H bridge test: SW leg shorted Replace the A04 Therapy PCB
9c1c 3:00 AM H bridge test: east side stuck open Replace the A04 Therapy PCB
9c1d 3:00 AM H bridge test: west side stuck open Replace the A04 Therapy PCB
9c1e 3:00 AM H bridge test: charge time out of range 1. Perform TCP - defibrillator calibration
2. Clear Service Log
6-36
