LIFEPAK 20/20e Defibrillator/Monitor Safety
Symbols (continued)
[signal] Output
Sync in/ECG out
System connector/data in
HOME SCREEN button
Alarm off
Alarm on
Biphasic defibrillator shock
Shock button
Shock count (x) on screen
Joules
(Continued on next page)
(x)
J
