Pinnacle Systems, Inc. TARGA 3000 User Manual

146
Appendix A: TARGA 3000 Effects Guide
Fade Right Example
The function of each node is as follows:
Compositor -- Performs the mix between the transformed Foreground A with the
Background B. The mixer page on the Compositor is where the fade is programmed by
altering the matte key value associated with the foreground input.
Transform -- Performs the 2D motion path of the image before it is keyed.
Blink Tall Example
The function of each node is as follows:
Compositor -- Mixes Foreground A which passes through a number of transforms with
Background B, which undergoes similar processing.
Transform -- The shape page performs the 2D squeeze of the Foreground A.
Transform -- The shape page performs the 2D squeeze on the Background B.
