51Pinnacle Systems TARGA 3000
From the “Device” pull-down within the dialog, select the method of device control you
will be using, then click “Options” for the type of control selected. Once settings specific
to the type of device have been made, click “OK” for the Preferences dialog window. A
new set of software controls for the device similar to the one shown below will displayed
within the Movie Capture window of Adobe Premiere.
DV 1394 Device Control
TARGA 3000 supports the following functions with DV 1394 device control:
Note: Even though the software supports the functions listed, the DV Device you have may or may not
support all of the functions listed.
• Frame forward, frame backwards
*
• Position information (the time code)
• Locate commands , seeks to a specific time code
*
• Basic functions (Stop/Rewind/Fast Forward/Playback/Pause)
• Batch capture, in combination with any capture plug-ins
• Jog Shuttle functions
The device controls are accessible in various Premiere windows. Consult the Adobe
Premiere User Manual for details on how to control a device from Premiere.
Tips
Suppose that you wanted to start the cut at time code 01:00:00:00. What was the frame
number at the start of the cut after the project was transferred? If it was at 01:00:00:01 or
more, the clip was started too early. Therefore, you should enter a smaller number of
frames under “Preroll.” Repeat the test until you arrive at a satisfactory result.
If the first frame at the start of the cut was black, or if you saw repeated frames, then the
clip was started too late. Try setting a higher number of frames for the “Preroll.”
