Chapter 1: Description
Expansion Modules
14 Quantum Scalar i6000 User’s Guide
Power System on page 38
Figure 9 SEM with 24 Slot I/E
Station
I/E station 24 slot
(optional)
cartridge
magazines
drive cluster
(optional)
drive side door side
