Quantum Scalar i6000 - Control Module

Chapter 1: Description
Control Module
10 Quantum Scalar i6000 User’s Guide
Figure 6 Right Parking Module
Slot Configuration (Dual
Robotics Only)
Control Module
All libraries contain a control module. A single-frame library consists of a
control module only. The control module manages library operations via
the library management module and includes an operator panel touch
screen for local operator use. For more information, see:
• Library Management Module on page 18
• Support for WORM on page 36
Rack 1 (rear wall)
Rack 2 (door)
= columns
unavailable
for storage
Optional drive
clusters
Optional
24-slot
I/E
station
= Calibration
target
