Chapter 1: Description
Dual Robotics Configurations and Parking Modules
Quantum Scalar i6000 User’s Guide 9
Figure 5 Left Parking Module
Slot Configuration (Dual
Robotics Only)
Rack 1 (rear wall)
Rack 2 (door)
= Columns
unavailable
for storage
= Calibration
target
