Chapter 1: Description
Dual Robotics Configurations and Parking Modules
8 Quantum Scalar i6000 User’s Guide
Figure 4 Dual Robotics Library
Side panels, doors, and door posts have been removed for clarity.
Control
module
(Position 1)
Left parking space
(left-most two columns)
Expansion
module
(Position 2)
Right parking
module
(Position 3)
Right parking space
(right-most two columns)
Left parking
module
(Position 0)
