Chapter 15: Maintaining Your Library
Maintaining Air Filters
Quantum Scalar i6000 User’s Guide 685
Removing an Air Filter Use these instructions to remove either a top or bottom air filter.
Required tools: #1 Phillips screwdriver
FRU ID: 1001 (air filter)
1 Take the library offline.
For information about taking the library offline, see Changing the
Library’s State on page 475.
2 On the operator panel, press Robotics Enabled to turn off power to
the picker and return it to the home position. The power is on to all
other components.
3 Open the access door. Aisle power is disabled.
4 Use the Phillips screwdriver to unscrew the two retaining
thumbscrews. The screws remain attached to the retaining bar.
5 Remove the air filter.
6 Use water and a mild soap to clean the air filter.
7 Allow them to dry.
thumbscrew
retaining bar
thumbscrew
