Chapter 1: Description
Control Module
Quantum Scalar i6000 User’s Guide 11
The control module also contains all of the other components common
to expansion modules, including:
• Import/Export Stations on page 25
• Tape Drives and Media on page 33
• Cartridges on page 28
• Cartridge Magazines on page 29
• Power System on page 38
The control module always occupies module position 1 in the library. (In
dual-robotics configurations, the left parking module is in position 0.)
Figure 7 Front and Back View
of the Control Module
power
supplies
library
management
magazines
module
drive
picker
I/E
station
accessor
and
cartridge
slots
front view back view
clusters
I/O
management
unit
