Chapter 1: Description
Control Module
12 Quantum Scalar i6000 User’s Guide
Figure 8 Front and Back View
of a Series 3 Control Module
(CM3)
Power
supplies
Library
management
Magazines
module
Drive
Robot
24-slot
and
cartridge
slots
front view
rear view
clusters
I/O
management
unit
I/E station
