Chapter 10: Path Failover
Configure Control Path
Quantum Scalar i6000 User’s Guide 371
Table 32 Example Path List
ACPF Configuration
1 Access the appropriate screen in one of two ways:
• From the SNW Wizard: Select Setup > SNW Wizard. Click Next.
From the Select Storage Networking Option screen, select
Control Path and click Next. See
Use the Storage Networking
Wizard on page 358.
•Select Setup > Partitions > Control Path from the main
console.
The Control Path Configuration dialog box appears, displaying all
partitions that contain drives eligible to be a control path.
SAN
Addressed Logical
Unit
Port
Example SCSI
Address
Example Logical Unit
Worldwide Identifiers
1 Tape drive 1 A ID 1 LUN 0 50:01:10:a0:00:00:00:01
1 Library Controller A ID 1 LUN 1 50:01:10:a0:00:00:00:02
2 Tape drive 1 B ID 2 LUN 0 50:01:10:a0:00:00:00:01
2 Library Controller B ID 2 LUN 1 50:01:10:a0:00:00:00:02
1 Tape drive 2 A ID 3 LUN 0 50:01:10:a0:00:00:00:03
1 Library Controller A ID 3 LUN 1 50:01:10:a0:00:00:00:02
2 Tape drive 2 B ID 4 LUN 0 50:01:10:a0:00:00:00:03
2 Library Controller B ID 4 LUN 1 50:01:10:a0:00:00:00:02
