Chapter 1: Description
Cartridge Magazines
30 Quantum Scalar i6000 User’s Guide
Figure 18 Magazine and Drive
Locations in the Control
Module
I/E
cartridge
magazines
station
door sidedrive side
drives or
storage
upper
drive
cluster
lower
drive
cluster
