Chapter 15: Maintaining Your Library
Monitoring the Library
Quantum Scalar i6000 User’s Guide 547
2 On the menu bar, click Monitor > EKM Servers. The EKM Server
Status dialog box appears.
For each server, the EKM Server Status dialog box displays the
following information - the table describes the elements on the EKM
Server Status dialog box.
.
Element Description
Type The encryption server type (Q-EKM, SKM, KMIP).
Status The current status of the server:
Note: Note: When the server indicates a “Running” status, this
server will receive the next key request.
Q-EKM — Active, Standby or Not Configured
SKM — Active Running, Standby Running or Down, or Not
Configured
KMIP — Active Running, Standby Running or Down, or Not
Configured
IP Address/Name The IP or host name of the server.
Port The server port number:
Q-EKM— Default 3801 for non-SSL and 443 for SSL
SKM — default 6000
KMIP — 5696
State Whether the server is Primary or Secondary.
