SERVICE PROGRAM MODE TABLES
SM 5-67 B291/B295/B296/B297
Service
Tables
5967* Copy Server Set Function 0: ON, 1: OFF
Enables and disables the document server. This is a security measure that
prevents image data from being left in the temporary area of the HDD. After
changing this setting, you must switch the main switch off and on to enable the
new setting.
Debug Serial Output DFU 5970*
Determines whether the debug information is output by the serial port when the
machine is powered on.
[0~1 / 0 / 1]
0: Disable
1: Enable
5974 Cherry Server
Selects which version of the Scan Router application program, “Light” or “Full
(Professional)”, is installed.
[0 ~ 1 / 0 / 1 /step]
0: Light version (supplied with this machine)
1: Full version (optional)
5985 Device Setting
The NIC and USB support features are built into the GW controller. Use this SP
to enable and disable these features. In order to use the NIC and USB functions
built into the controller board, these SP codes must be set to "1".
5985 1 On Board NIC
5985 2 On Board USB
0: Disable 1: Enable
5990 SP Print Mode (SMC Printout)
5990 1 All (Data List)
5990 2 SP (Mode Data List)
5990 3 User Program
5990 4 Logging Data
5990 5 Diagnostic Report
5990 6 Non-Default
5990 7 NIB Summary
5990 8 Capture Log
5990 21 Copier User Program
5990 22 Scanner SP
5990 23 Scanner User Program
Prints all of the system parameter lists for the item
selected. ( 5.2.7) Input the number for the item that
you want to print, and then press : “Execute” on the
touch panel.
