Rockwell Automation Allen-Bradley E300

122 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 4 System Operation and Configuration
Table 155 - Analog Module 4 – Output Channel 00 Type (Parameter 557)
Analog Module 4 – Output Channel 00 Selection
Analog Module 4 – Output Channel 00 Selection (Parameter 558) defines the
E300 Electronic Overload Relay parameter that Output Channel 00 will be
representing.
Table 156 - Analog Module 4 – Output Channel 00 Selection (Parameter 558)
Analog Module 4 – Output Channel 00 Expansion Bus Fault Action
Analog Module 4 – Output Channel 00 Expansion Bus Fault Action (Parameter
559) defines the value that the E300 Analog I/O Expansion Module Output
Channel 00 provides when there is an E300 Expansion Bus fault.
Table 157 - Analog Module 4 – Output Channel 00 Expansion Bus Fault Action (Parameter 559)
Analog Module 4 – Output Channel 00 Protection Fault Action
Analog Module 4 – Output Channel 00 Expansion Bus Fault Action (Parameter
560) defines the value that the E300 Analog I/O Expansion Module Output
Channel 00 provides when the E300 is in a tripped state.
Value Assignment Description
0 Disabled Disable the analog input
1 4To20mA Provide an analog current signal from 4…20 mA
2 0To20mA Provide an analog current signal from 0…20 mA
3 0To10Volts Provide an analog voltage signal from 0…10 V DC
4 1To5Volts Provide an analog voltage signal from 1…5 V DC
5 0To5Volts Provide an analog voltage signal from 0…5 V DC
Value Assignment Description
0 AveragePCTFLA Average %FLA (0…100%)
1 ScaledAvgPctFLA Scaled Average %FLA (0…200%)
2 PercentTCU %TCU (0…100%)
3 GFCurrent Ground Fault Current (Ground Fault Type Range)
4 CurrentImbalance Current Imbalance (0…100%)
5 AvgLLVoltage Average L-L Voltage (0…PT Primary)
6 VoltLLImbalance
Voltage Imbalance (0…100%)
7 TotalkW Total kW (0…FLA x PT Primary x 1.732)
8 TotalkVA Total kVA (0…FLA x PT Primary x 1.732)
9 Total kVAR Total kVAR (0…FLA x PT Primary x 1.732)
10 TotalPF Total Power Factor (-50% Lagging…+50% Leading)
11 UserDLXData User-defined Value (-32768…32767)
Value Assignment Description
0 Zero Provide an analog signal of zero
1 Maximum Provide an analog signal equal to the high limit
2 Minimum Provide an analog signal equal to the low limit
3 HoldLastState Provide the last known analog signal
