Rockwell Automation Allen-Bradley E300

186 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 224 - Voltage Trip Status (Parameter 5)
Table 225 - Voltage Warning Status (Parameter 11)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Under Voltage Trip
X
Over Voltage Trip
X
Voltage Imbalance Trip
X
Phase Rotation Mismatch Trip
X
Under Frequency Trip
X
Over Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit
1514131211109876543210 Function
X
Under Voltage Warning
X
Over Voltage Warning
X
Voltage Imbalance Warning
X
Phase Rotation Mismatch Warning
X
Under Frequency Warning
X
Over Frequency Warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
