192 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 231 - Over Voltage Trip Level (Parameter 361)
Over Voltage Warning
The E300 Electronic Overload Relay indicates an Over Voltage warning if:
• No warning currently exists
• Over Voltage Warning is enabled
• Voltage is present
• Over Voltage Inhibit Time has expired
• The maximum phase voltage is equal to or greater than the Over Voltage
War n in g L e v el
When the Over Voltage Warning conditions are satisfied, the:
• TRIP/WARN LED flashes a yellow 1-long / 2-short blink pattern
• Bit 1 in Voltage Warning Status (Parameter 11) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm closes
Over Voltage Warn Level
Over Voltage Warn Level (Parameter 362) allows you to define the voltage at
which the E300 Electronic Overload Relay indicates a warning. It is user-
adjustable from 0…6553.5 volts.
Table 232 - Over Voltage Warn Level (Parameter 362)
Default Value 500.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
The Over Voltage Inhibit Time starts after a phase voltage transitions from 0V
to 20V L-L. The E300 Electronic Overload Relay does not begin monitoring for
an over voltage condition until the Over Voltage Inhibit Time expires.
Default Value 490.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
