246 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Control Trip Status (Parameter 7) and Control Warning Status (Parameter 13)
are used to monitor the respective current-based protective trip and warning
functions.
Table 301 - Control Warning Enable (Parameter 192)
Table 302 - Control Trip Status (Parameter 7)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
Reserved
Reserved
X
DeviceLogix Warning Enable
X
Operator Station Warning Enable
Reserved
Reserved
Reserved
Reserved
X
Option Match Warning Enable
X
Feedback Timeout Warning Enable
X
Expansion Bus Warning Enable
X
Number Of Starts Warning Enable
X
Operating Hours Warning Enable
Reserved
Reserved
Reserved
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Test Trip
X
PTC Trip
X
DeviceLogix Trip
X
Operator Station Trip
X
Remote Trip
X
Blocked Start Trip
X
Hardware Fault Trip
X
Configuration Trip
X
Option Match Trip
X
Feedback Timeout Trip
X
Expansion Bus Trip
Reserved
Reserved
X
Nonvolatile Memory Trip
X
Test Mode Trip
Reserved
