Chapter 6 Protective Trip and Warning Functions
Table 313 - Analog Warning Enable (Parameter 193)
Analog Trip Status (Parameter 8) and Analog Warning Status (Parameter 14) are
used to monitor the respective analog-based protective trip and warning
functions.
Table 314 - Analog Trip Status (Parameter 8)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XAnalog Module 1 - Input Channel 00 Warning
XAnalog Module 1 - Input Channel 01 Warning
XAnalog Module 1 - Input Channel 02 Warning
XAnalog Module 2 - Input Channel 00 Warning
XAnalog Module 2 - Input Channel 01 Warning
XAnalog Module 2 - Input Channel 02 Warning
         X       Analog Module 3 - Input Channel 00 Warning
        X        Analog Module 3 - Input Channel 01 Warning
XAnalog Module 3 - Input Channel 02 Warning
XAnalog Module 4 - Input Channel 00 Warning
XAnalog Module 4 - Input Channel 01 Warning
XAnalog Module 4 - Input Channel 02 Warning
Bit
1514131211109876543210 Function
XAnalog Module 1 - Input Channel 00 Trip
XAnalog Module 1 - Input Channel 01 Trip
XAnalog Module 1 - Input Channel 02 Trip
XAnalog Module 2 - Input Channel 00 Trip
XAnalog Module 2 - Input Channel 01 Trip
XAnalog Module 2 - Input Channel 02 Trip
XAnalog Module 3 - Input Channel 00 Trip
XAnalog Module 3 - Input Channel 01 Trip
XAnalog Module 3 - Input Channel 02 Trip
XAnalog Module 4 - Input Channel 00 Trip
XAnalog Module 4 - Input Channel 01 Trip
XAnalog Module 4 - Input Channel 02 Trip
