266 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 321 - Analog Module 1 – Channel 01 Warning Level (Parameter 454)
Analog Module 1 – Channel 02 Over Level Trip
The E300 Electronic Overload Relay trips with an Analog Module 1 – Channel
02 Over Level Trip indication if:
No trip currently exists
Analog Module 1 – Channel 02 Over Level Trip is enabled
The measured analog input signal is greater than the Analog Module 1
Channel 02 Trip Level for a time period greater than the Analog Module 1
– Channel 02 Over Level Trip Delay.
If the E300 Electronic Overload Relay trips on an Analog Module 1 – Channel
02 Over Level, the:
TRIP/WARN LED status indicator flashes a red 4-long / 3-short blink
pattern
Bit 2 in Analog Trip Status (Parameter 8) sets to 1
Bit 0 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Trip Relay open
Any relay outputs configured as a Control Relay open
Any relay outputs configured as a Trip Alarm close
Any relay outputs configured as a Normal Relay are placed in their
Protection Fault state (if so programmed)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
