268 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 323 - Analog Module 1 – Channel 02 Trip Level (Parameter 462)
Analog Module 1 – Channel 02 Over Level Warning
The E300 Electronic Overload Relay indicates an Analog Module 1 – Channel
02 Over Level warning if:
• No warning currently exists
• Analog Module 1 – Channel 02 Over Level Warning is enabled
• The maximum phase current is equal to or greater than the Analog
Module 1 – Channel 02 Warning Level
When the Analog Module 1 – Channel 02 Over Level Warning conditions are
satisfied, the:
• TRIP/WARN LED flashes a yellow 4-long / 3-short blink pattern
• Bit 2 in Analog Warning Status (Parameter 14) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm closes
Analog Module 1 – Channel 02 Warning Level
Analog Module 1 – Channel 02 Warning Level (Parameter 463) allows you to
define the magnitude of the analog signal in which the E300 Electronic Overload
Relay trips on an Analog Module 1 – Channel 02 Over Level warning. It is user-
adjustable from -32768…+32767.
Table 324 - Analog Module 1 – Channel 02 Warning Level (Parameter 463)
Analog Module 2
The E300 Analog I/O Expansion Module scans up to three analog signals. An
over level trip or warning can be configured for each input channel.
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
