Protective Trip and Warning Functions Chapter 6
Table 329 - Analog Module 2 – Channel 01 Trip Level (Parameter 484)
Analog Module 2 – Channel 01 Over Level Warning
The E300 Electronic Overload Relay indicates an Analog Module 2 – Channel
01 Over Level warning if:
• No warning currently exists
• Analog Module 2 – Channel 01 Over Level Warning is enabled
• The maximum phase current is equal to or greater than the Analog
Module 2 – Channel 01 Warning Level
When the Analog Module 2 – Channel 01 Over Level Warning conditions are
satisfied, the:
• TRIP/WARN LED flashes a yellow 4-long / 5-short blink pattern
• Bit 4 in Analog Warning Status (Parameter 14) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm closes
Analog Module 2 – Channel 01 Warning Level
Analog Module 2 – Channel 01 Warning Level (Parameter 485) allows you to
define the magnitude of the analog signal in which the E300 Electronic Overload
Relay trips on an Analog Module 2 – Channel 01 Over Level warning. It is user-
adjustable from -32768…+32767.
Table 330 - Analog Module 2 – Channel 01 Warning Level (Parameter 485)
Analog Module 2 – Channel 02 Over Level Trip
The E300 Electronic Overload Relay trips with an Analog Module 2 – Channel
02 Over Level Trip indication if:
• No trip currently exists
• Analog Module 2 – Channel 02 Over Level Trip is enabled
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
