278 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 335 - Analog Module 3 – Channel 00 Trip Level (Parameter 506)
Analog Module 3 – Channel 00 Over Level Warning
The E300 Electronic Overload Relay indicates an Analog Module 3 – Channel
00 Over Level warning if:
No warning currently exists
Analog Module 3 – Channel 00 Over Level Warning is enabled
The maximum phase current is equal to or greater than the Analog
Module 3 – Channel 00 Warning Level
When the Analog Module 3 – Channel 00 Over Level Warning conditions are
satisfied, the:
TRIP/WARN LED flashes a yellow 4-long / 7-short blink pattern
Bit 6 in Analog Warning Status (Parameter 14) sets to 1
Bit 1 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Warning Alarm close
Analog Module 3 – Channel 00 Warning Level
Analog Module 3 – Channel 00 Warning Level (Parameter 507) allows you to
define the magnitude of the analog signal in which the E300 Electronic Overload
Relay trips on an Analog Module 3 – Channel 00 Over Level warning. It is user-
adjustable from -32768…+32767.
Table 336 - Analog Module 3 – Channel 00 Warning Level (Parameter 507)
Analog Module 3 – Channel 01 Over Level Trip
The E300 Electronic Overload Relay trips with an Analog Module 3 – Channel
01 Over Level Trip indication if:
No trip currently exists
Analog Module 3 – Channel 01 Over Level Trip is enabled
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
