Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 295
Commands Chapter 7
184 TripEnableV 0 322 OutDig1PrFltAct Goto
Value
446 InAnMod1Ch01Type Disable
185 TripEnableP 0 323 OutDig1PrFltVal Open 447 InAMod1Ch1Format Eng Units
186 TripEnableC 0x20C9 324 OutDig1ComFltAct Goto
Value
448 InAMod1C1TmpUnit Degrees C
187 TripEnableA 0 325 OutDig1ComFltVal Open 449 InAMod1C1FiltFrq 17 Hz
189 WarningEnableI 0 326 OutDig1ComIdlAct Goto
Value
450 InAMod1C1OpCktSt Upscale
190 WarningEnableV 0 327 OutDig1ComIdlVal Open 451 InAnMod1Ch1RTDEn 3-Wire
191 WarningEnableP 0 328 OutDigp2PrFltAct Goto
Value
452 InAMod1C1TripDly 1.0
Second
s
192 WarningEnableC 0 329 OutDig2PrFltVal Open 453 InAMod1C1TripLvl 0
193 WarningEnableA 0 330 OutDig2ComFltAct Goto
Value
454 InAMod1C1WarnLvl 0
195 SetOperatingMode Net
Overload
331 OutDig2ComFltVal Open 455 InAnMod1Ch02Type Disable
196 InPt00Assignment Normal 332 OutDig2ComIdlAct Goto
Value
456 InAMod1Ch2Format Eng Units
197 InPt01Assignment Normal 333 OutDig2ComIdlVal Open 457 InAMod1C2TmpUnit Degrees C
198 InPt02Assignment Normal 334 OutDig3PrFltAct Goto
Value
458 InAMod1C2FiltFrq 17 Hz
199 InPt03Assignment Normal 335 OutDig3PrFltVal Open 459 InAMod1C2OpCktSt Upscale
200 InPt04Assignment Normal 336 OutDig3ComFltAct Goto
Value
460 InAnMod1Ch2RTDEn 3-Wire
201 InPt05Assignment Normal 337 OutDig3ComFltVal Open 461 InAMod1C2TripDly 1.0
Second
s
202 OutPt0Assignment * Trip Relay 338 OuDig3ComIdlAct Goto
Value
462 InAMod1C2TripLvl 0
203 OutPt1Assignment Normal 339 OutDig3ComIdlVal Open 463 InAMod1C2WarnLvl 0
204 OutPt2Assignment Normal 340 OutDig4PrFltAct Goto
Value
464 OutAnMod1Type Disable
205 StartsPerHour 2 341 OutDig4PrFltVal Open 465 OutAnMod1Select Ave %FLA
206 StartsInterval 600
Second
s
342 OutDig4ComFltAct Goto
Value
466 OutAnMod1FltActn Zero
207 PMTotalStarts 0 343 OutDig4ComFltVal Open 467 OutAnMod1IdlActn Zero
208 PMOperatingHours 0 Hrs 344 OutDig4ComIdlAct Goto
Value
468 InAnMod2Ch00Type Disable
209 ActFLA2wOutput Disable 345 OutDig4ComIdlVal Open 469 InAMod2Ch0Format Eng Units
211 SecurityPolicy 0x801F 346 CommOverride Disable 470 InAMod2C0TmpUnit Degrees C
212 Language English 347 NetworkOverride Disable 471 InAMod2C0FiltFrq 17 Hz
213 FeedbackTimeout 500 350 PtDevOutCOSMask 0x0000 472 InAMod2C0OpCktSt Upscale
214 TransitionDelay 10000 352 VoltageMode Delta 473 InAnMod2Ch0RTDEn 3-Wire
215 InterlockDelay 100 353 PTPrimary 480 474 InAMod2C0TripDly 1.0
Second
s
216 EmergencyStartEn Disable 354 PTSecondary 480 475 InAMod2C0TripLvl 0
221 ControlModuleTyp Ignore 355 UVInhibitTime 10
Second
s
476 InAMod2C0WarnLvl 0
Number Parameter Name Default
Value
Units Number Parameter Name Default
Value
Units Number Parameter Name Default
Value
Units
