Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 297
Commands Chapter 7
251 JamInhibitTime 10
Second
s
380 UWTripLevel 0.000 kW 501 InAMod3C0TmpUnit Degrees C
252 JamTripDelay 5.0
Second
s
381 UWWarningLevel 0.000 kW 502 InAMod3C0FiltFrq 17 Hz
253 JamTripLevel 250 %FLA 382 OWInhibitTime 10
Second
s
503 InAMod3C0OpCktSt Upscale
254 JamWarningLevel 150 %FLA 383 OWTripDelay 1.0
Second
s
504 InAnMod3Ch0RTDEn 3-Wire
255 ULInhibitTime 10
Second
s
384 OWTripLevel 0.000 kW 505 InAMod3C0TripDly 1.0
Second
s
256 ULTripDelay 5.0
Second
s
385 OWWarningLevel 0.000 kW 506 InAMod3C0TripLvl 0
257 ULTripLevel 50 %FLA 386 UVARCInhibitTime 10
Second
s
507 InAMod3C0WarnLvl 0
258 ULWarningLevel 70 %FLA 387 UVARCTripDelay 1.0
Second
s
508 InAnMod3Ch01Type Disable
259 CIInhibitTime 10
Second
s
388 UVARCTripLevel 0.000 kVAR 509 InAMod3Ch1Format Eng Units
260 CITripDelay 5.0
Second
s
389 UVARCWarnLevel 0.000 kVAR 510 InAMod3C1TmpUnit Degrees C
261 CITripLevel 35 % 390 OVARCInhibitTime 10
Second
s
511 InAMod3C1FiltFrq 17 Hz
262 CIWarningLevel 20 % 391 OVARCTripDelay 1.0
Second
s
512 InAMod3C1OpCktSt Upscale
263 CTPrimary 5 392 OVARCTripLevel 0.000 kVAR 513 InAnMod3Ch1RTDEn 3-Wire
264 CTSecondary 5 393 OVARCWarnLevel 0.000 kVAR 514 InAMod3C1TripDly 1.0
Second
s
265 UCInhibitTime 10
Second
s
394 UVARGInhibitTime 10
Second
s
515 InAMod3C1TripLvl 0
266 L1UCTripDelay 1.0
Second
s
395 UVARGTripDelay 1.0
Second
s
516 InAMod3C1WarnLvl 0
267 L1UCTripLevel 35 % 396 UVARGTripLevel 0.000 kVAR 517 InAnMod3Ch02Type Disable
268 L1UCWarningLevel 40 % 397 UVARGWarnLevel 0.000 kVAR 518 InAMod3Ch2Format Eng Units
269 L2UCTripDelay 1.0
Second
s
398 OVARGInhibitTime 10
Second
s
519 InAMod3C2TmpUnit Degrees C
270 L2UCTripLevel 35 % 399 OVARGTripDelay 1.0
Second
s
520 InAMod3C2FiltFrq 17 Hz
271 L2UCWarningLevel 40 % 400 OVARGTripLevel 0.000 kVAR 521 InAMod3C2OpCktSt Upscale
272 L3UCTripDelay 1.0
Second
s
401 OVARGWarnLevel 0.000 kVAR 522 InAnMod3Ch2RTDEn 3-Wire
Number Parameter Name Default
Value
Units Number Parameter Name Default
Value
Units Number Parameter Name Default
Value
Units
