Rockwell Automation Publication 193-UM015D-EN-P - February 2015 361
Metering and Diagnostics Chapter 8
Table 477 - Current Trip History Mask (Parameter 139)
Voltage Trip History Mask
Voltage Trip History Mask (Parameter 140) allows you to select which voltage-
based trip events are recorded in the trip history.
Table 478 - Voltage Trip History Mask (Parameter 140)
Power Trip History Mask
Power Trip History Mask (Parameter 141) allows you to select which power-
based trip events are recorded in the trip history.
Bit
1514131211109876543210 Function
XOverload Trip
X Phase Loss Trip
X Ground Fault Trip
X Stall Trip
X Jam Trip
X Underload Trip
X Current Imbalance Trip
X L1 Under Current Trip
X L2 Under Current Trip
X L3 Under Current Trip
X L1 Over Current Trip
X L2 Over Current Trip
X L3 Over Current Trip
X L1 Line Loss Trip
X L2 Line Loss Trip
X L3 Line Loss Trip
Bit
1514131211109876543210 Function
XUnder Voltage Trip
X Over Voltage Trip
X Voltage Imbalance Trip
X Phase Rotation Trip
X Under Frequency Trip
X Over Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
